Cleal CP-05 Cartridge Filter JNC Chisso 5 Micron

Description

Cleal CP-05 Cartridge Filter JNC Chisso 5 Micron merupakan elemen filter kartrid yang ditujukan untuk kebutuhan filtrasi industri dengan spesifikasi penyaringan 5 mikron. Produk ini dapat dipertimbangkan untuk sistem filtrasi yang membutuhkan elemen filter dengan tingkat penyaringan tersebut, sesuai karakteristik cairan dan persyaratan proses yang digunakan.

Dalam pemilihan Cleal CP-05 Cartridge Filter, beberapa aspek penting perlu diperhatikan, termasuk ukuran kartrid, kompatibilitas material, tekanan dan temperatur operasi, serta kesesuaian dengan rumah filter yang digunakan. Pemeriksaan spesifikasi teknis sebelum pembelian membantu memastikan bahwa produk sesuai dengan kebutuhan instalasi. Untuk keperluan penggantian filter maupun pengadaan komponen baru, verifikasi kode model dan rating filtrasi menjadi langkah penting agar pemilihan produk lebih tepat.

Watermaker Indonesia merupakan distributor agen dan supplier Cleal CP-05 Cartridge Filter JNC Chisso 5 Micron terlengkap dari PT PROFILTER INDONESIA menyediakan berbagai kebutuhan spare part filter untuk keperluan industrial water treatment dengan kualitas dan harga terbaik.

CLEAL CP Filter Cartridge JNC Chisso

CLEAL CP merupakan depth filter cartridge dengan media berbasis polypropylene dan polyethylene bi-component fiber. Series ini tersedia dalam berbagai nominal micron rating untuk kebutuhan liquid filtration industri.

Current CP lineup mencakup:

• CP-01 Filter Cartridge 1 Micron
• CP-03 Filter Cartridge 3 Micron
• CP-05 Filter Cartridge 5 Micron
• CP-10 Filter Cartridge 10 Micron
• CP-25 Filter Cartridge 25 Micron
• CP-50 Filter Cartridge 50 Micron
• CP-75 Filter Cartridge 75 Micron
• CP-100 Filter Cartridge 100 Micron

Untuk pembahasan teknologi, pilihan micron dan konfigurasi CP secara lebih lengkap, lihat CLEAL CP Series JNC Filter Cartridge.

Features Structure Cleal CP-05 Cartridge Filter JNC Chisso 5 Micron

Only polyolefin thermally bonded bi-component fibers (ES fibers) are used, and the fiber-to-fiber bond forms a stable porosity.

Advantages

• The ES fibers uniquely developed and patented by JNC are used, and the fiber-to-fiber bond at each contact point featuring integral rigid thermally bonded construction enables consistent filtration and eliminates pore size variability and media migration.
• The density graded construction provides long service life.
• The simple but clean and rigid structure utilizing state-of-the-art fiber technology allows for longer service life and higher throughputs.
• A rigid filter structure of fused ES fibers in a three dimensional network with a high tolerance for differential pressure is achieved.
• The diameter of the structural fibers is changed for every grade, and the grades are clearly differentiated from a nominal filtration size of 1μm to 200μm.

Specification Cleal CP-05 Cartridge Filter JNC Chisso 5 Micron

• Media : Polyethylene and Polypropylene
• End Parts : Polypropylene
• O-ring : NBR, EPDM, Silicone, FKM (Fluorine Rubber), E-FKM (Encapsulated Fluorine Rubber)
• Filtration rate Nominal : 5 micron
• Dimension
  • Double open ended:
    • ID x OD x Length :
      • 30mm x 68mm x 125, 250, 254, 500, 508, 750, 762, 1000, 1016 mm
      • 28mm x 64mm x 124, 127, 248, 254, 496, 508, 743, 762, 992, 1016 mm
  • Single open ended:
    • ID x OD x Length :
      • 25mm x 70mm x 10”, 20”, 30”, 40”
• Operating Conditions
  • Maximum Operating Temperature: 80°C (175°F)
  • Replacement Differential Pressure: 0.15MPa (22psi)
  • Maximum Differential Pressure: 0.55MPa (80psi) @ 20°C (68°F)

＊ depending on operating parameters

Quality

• CP medium Complies with CFR 21 FDA regulations
• Complies with RoHS regulations
• Complies with REACH regulations
• NSF certified elements of DOE type
• Production at ISO 9001 certified factory
• Production at ISO 14001 certified factory

Application Cleal CP-05 Cartridge Filter

• General Industry :
  • Cleaning water, pre-filter for ultra pure water etc.
• Chemicals :
  • Paint, Ink, Resins, Adhesives, Catalysts, Solvents, Surfactants etc.
• Food & Beverages :
  • Tea, Juices, Wine, Spirits, Soy sauce, Soups, Vinegar, Syrup etc.
• Electronics :
  • Pure water, Optical films, PCB, FPC, Shadow masks, Lead frames, TAB, Electrolyzed copper foils, Ceramic capacitors , Resist etc

Untuk informasi lengkap dan permintaan penawaran harga Cleal CP-05 Cartridge Filter JNC Chisso 5 Micron silahkan hubungi kantor kami.
